Automotive & Heavy-Duty ECU Board Repair Ebook

Product Description

• ECU electronic component fundamentals
• SMD component identification
• Diode, transistor and MOSFET testing
• Power-supply and voltage-regulation circuits
• Injector high-side and low-side driver circuits
• Boost and high-voltage ECU circuits
• CAN communication and signal-processing sections
• Current-sensing and protection circuits
• CPU, RAM, EEPROM and memory identification
• Real automotive and heavy-duty ECU board layouts
• ECU disassembly examples and repair-tool overview

Whether you work with cars, commercial vehicles, diesel engines or heavy-duty ECUs, this guide provides a practical visual reference to help you better understand ECU electronics and approach circuit-board diagnosis with greater confidence.

212 Pages • Fully Illustrated • Automotive & Heavy-Duty • Professional ECU Reference Guide

The Complete Illustrated Guide to ECU Electronics, Components & Circuit Diagnosis.

This manual starts with the essential building blocks of ECU electronics — including resistors, capacitors, diodes, transistors, MOSFETs, inductors, ferrite beads, and crystal oscillators — before moving into detailed real-world ECU circuit-board analysis.

Learn how to identify electronic components, understand their function inside an ECU, use a multimeter for component testing, recognize power-supply and driver circuits, and locate critical areas such as injector drivers, CAN communication circuits, boost stages, voltage regulators, current-sensing circuits, memory, CPUs, and protection components.

The practical ECU section includes detailed board overviews and internal component identification for systems including:

Bosch EDC7 • EDC16C39 • EDC16UC40 • EDC16C8 • EDC17C55 • EDC17CV44 • Cummins CM800 • CM2220 • CM2880 • Hino Denso C31 • Delphi DCM3.2 • Weichai • Xichai • Yuchai • EControls and more.

Each illustrated example helps you understand how real ECU boards are organized and where important electronic circuits and components are located.

For automotive technicians, ECU repair specialists, diagnostic professionals and electronics enthusiasts who work on car, commercial-vehicle, diesel and heavy-duty ECUs and want a practical visual reference for board-level diagnosis.

Table of Contents

• ECU electronic component fundamentals
• SMD component identification
• Resistors, capacitors, inductors and ferrite beads
• Diode, transistor and MOSFET testing with a multimeter
• Crystal oscillators and clock circuits
• Power-supply and voltage-regulation circuits
• Injector high-side and low-side driver circuits
• Boost and high-voltage ECU circuits
• CAN communication and signal-processing sections
• Current-sensing and protection circuits
• CPU, RAM, EEPROM and memory identification
• Bosch EDC7, EDC16 and EDC17 board overviews
• Cummins CM800, CM2220 and CM2880 board overviews
• Hino Denso C31, Delphi DCM3.2, Weichai, Xichai, Yuchai and EControls boards
• ECU disassembly examples and repair-tool overview
