LAUNCH scan tool CRP919X BT loads super Android10.0 OS & 3+32GB memory, which can run faster vehicle diagnostics than ever. LAUNCH CRP919X BT is an upgraded version of CRP919X. With Bluetooth connectivity, you can quickly transfer diagnostic information and have no more limitations by the cable length, Be free to move around the vehicle portable VCI can easily fit inside your box.
LAUNCH CRP919X BT can connect car via bluetooth with added added DBScar VII VCI.
Highlights:
- TOP Hardware Configuration: >>>Upgrade top-level hardware for faster diagnostic speed, the newly upgraded X431 CRP919X BT with Android 10, 2.0Ghz 4 core high efficiency processor, 4GB RAM+64GB ROM large storage, 6300mAh rechargeable battery, 2.4GHz & 5GHz Wifi, which greatly increased the speed of running multiple task.
- Stable Wireless BT Connection: Compared with the wired diagnostic tool, X431 CRP919X BT is equipped with wireless BT technology, up to 33ft(10m) working range, enabling wireless diagnostic allows you getting away from annoying connection cable and narrow spaces in the car.
- ECU Coding & KEY Programming: used to customize your car, deploy hidden features, or disable annoying features (turn off reverse buzzer, turn off seat belt buzzer), Reidentify adaptive data for certain components after repair or replacement. Add new Keys, disable lost key.
- Wireless intelligent Diagnosis & OE-Level Full System Diagnostic: CRP919X BT OBD2 scanner can access all available car systems, and perform OE-level diagnosis by reading/clearing codes, viewing live data of multiple sensors in text&graph, freeze frame data,Just a few minutes, you can easily master the car situation.
- 35+ Services (Adaptation+Calibration+Initialization): Oil reset, ABS bleeding, injector coding, fuel adjustment learning, transmission reset, A/F setting, stop/start reset, SAS reset, TPMS reset, BMS reset, window initialization, power balance, VGT learning, seat calibration, etc
- Bi-Directional Control (Active Test): Performing various active tests to check the integrity of systems or components and the operation of various automotive systems or subsystems, without the use of vehicle control devices.
- VAG Guided Functions: With VAG Guide Functions, CRP919X BT can perform complex functions such as special functions, ECU coding, etc., to help your diagnostic step by step with instructions for VW/Audi/Skoda, etc
- Autoauth for FCA: Supports AutoAuth for FCA vehicles (Compatible with Chrysler, Dodge, Fiat, etc.) after 2017.(Note: Need AutoAuth subscriptions.)
- Support CANFD/DoIP: CAN-FD Compatible with GM models (2019 and later), NO CAN-FD Adapter Required, Saving 100+ bucks for you. DoIP Compatible with BMW (F&G chassis), Volvo models (2018 later), Land Rover & Jaguar models (2017 later), need Purchase extra DOIP Connector.
- 150+ Brands Coverage: Vehicle coverage is extensive, covering over 150+ brands, 100000+ in the Americas, Europe, and Asia (from 1996 to 2024).
- 2 Years Free Update: LAUNCH provides 2 years free upgrade, after two years the CRP919XBT will remain in the final updated version, and the offline function can still be used normally.
- 11+ Language Supports: English/French/Spanish/German/Italian/Russian/Portuguese/Japanese/Korean/Polish/Chinese. All languages are free to use, and you can switch back and forth between multiple languages as needed which can solve the language barrier you may encounter. On the home screen, tap Other Modules > Settings > System >Language & input > Languages.
- LAUNCH CRP919X BT is an upgraded version of CRP919X.
- LAUNCH scan tool CRP919X BT has the same function as CRP919E BT, but CRP919X BT can be shipped from the EU/EK/US warehouse.
LAUNCH CRP919X BT Functions:
Support automatic VIN code identification
OE- Level Full System Diagnosis
As an OE level automotive diagnostic tool, LAUNCH CRP919E can access most car ECUs to read, clear codes, retrieve live data, freeze frame, ECU information and perform active tests, matching, adaptation, turn off warning lights, reset monitors. Full range car models and full car system diagnose make it a professional automotive diagnostic tool.
Include : ABS System, Engine System, SAS System , TPMS System , IMMO System , Battery System ,Oil Service System , SRS System ,DPF System ,Air Conditioning System,Transmission System, etc...
Brief introduction of its capabilities in full systems diagnostic as follows:
1. For Engine System: help detect the engine ignition, fuel injection, air and fuel ratio, and exhaust emission conditions in Engine system to enhance vehicle performance, save energy and reduce exhaust emission.
2. For Transmission: It makes great sense in the safety driving when your car is slipping or difficult to shift, this diagnostic tool can figure the problems out via reading codes in the Transmission system, or check the health status via live data viewing.
3. For ABS System: Diagnosing an ABS problem should always start with a visual inspection of all brake components, next you will need to retrieve ABS codes to tell you where the problem is, and this is what this diagnostic does for you.
4. For SRS System: SRS, safety restraint system, is made up of impact sensors, a control module, and the airbags themselves, and this diagnostic tool can detect every electronic parameter to check its health status.
5. To diagnose Brake System if you feel the brake pedal is mushy and notice unusual odor or noise, etc. A properly operating brake system is critical to ensure safe vehicle control and operation;
6. To diagnose Emission System if the system is affected by vehicle age or poor quality fuel. A good emission system reduces harmful gases to a large degree and protects you from being fined;
7. To diagnose Fuel system if vehicle won’t start or “Check Engine” light is illuminated. Check car’s fuel system regularly ensures the best performance of your car with the lowest emissions;
8. To diagnose Transmission if your car is slipping or difficult to shift. The system plays an important part in the overall performance of your car;
9. To diagnose Wiper System if you observe chattering or streaking wiper. If the car is not regularly checked, the accident might happen because you can’t see clearly;
10. To diagnose Light System if you see rapid signal blinking or dimming lights. And many more ....
Supports CANFD and DIOP protocol now , it supports For GM after 2020 and other New cars !
it is the only product in this price range that is compatible with CAN-FD protocol and supports the latest For GM vehicles manufactured after 2020. Adopts advanced CRC algorithms to accommodate more data from 8 to 64 bytes in the CAN frame, which runs faster than other products and reduces the risk of undetected errors to greatly enhance the user experience.
Supports For Chevrolet Onix 2020-2021 year
Supports For Chevrolet Tracker 2020 year
Supports For Chevrolet Suburban 2021 year
Supports For Chevrolet Tahoe 2021 year
Supports For Buick
Supports For Cadillac Escalade 2021 year
Supports For Cadillac Escalade 2021 year
Supports For GMC Yukon 2021 year
Supports For GMC Yukon XL 2021 year
Supports For Holden
Supports For DAEWOO
Supports For Alpheon
Supports For Ravon
Supports For Pontiac
Supports For Saturn
Supports For Hummer
DoIP
With Diagnostics over DoIP, diagnostics introduced over UDS are used over TCP/IP and Ethernet. This enables much higher data rates than with CAN. That makes LAUNCH CRP919E save both in terms of time and expenses in the case of complex diagnostic tasks and flash applications. Compatible with BMW (F&G chassis), Volvo models (2018 later), Land Rover & Jaguar models (2017 later).
Bi-directional Control (Active Test)
Actuate solenoids and actuators for active testing, send commands to systems/components to test their working status, without using the vehicle controls.
ECU Coding
LAUNCH CRP919XBT also features the advanced ECU coding that most aftermarket obd2 scanner diagnostic tools do not support. You can address the following issues:
- Supports online coding of VW Audi
- Offline coding of Volkswagen Audi, Mercedes-Benz BMW, Land Rover Jaguar, Porsche, and Toyota.
- Match Settings after Replacement – After replacing the ECU/module, you need to match, learn, code, or even program the replacement before it functions normally. Otherwise, the car cannot start or some parts cannot work normally.
- Open/Close Car Functions (Personalization, Flash Hidden Functions) – With this car scanner diagnostic for all cars, you can access and modify certain hidden or advanced settings in a vehicle to make your general model a deluxe car.
- Using Scenario – Model: Ford Focus. Operation: you can modify some of original car features, such as how long the interior light stays on after you close the door, or whether the horn honks when you use your remote lo-cks.
- More Applications – Revised fu-el consumption calculation, seat belt alarm, automatic start/stop, hidden menu, daytime running lights, cruise control, automatic loc-king and unlo-cking of the central lo-ck, comfortable windscreen washer, welcome light and others.
- Restore Functions if Data Loss – By restoring the current car settings back to the default status, to fix complex ECU-controlled issues including low fu-el efficiency, mysterious power loss, unknown fault in mechanical parts, etc.
- Modifications/Changeover – Make personalized modifications to your car's per-formance, appearance, or both. It offers a wide range of popular modification options, including converting halogen to xenon headlights, altering tire size, automating manual electric control systems, upgrading steering gear, and more.
- Aftermarket Installation – Add new auto parts into an older vehicle to outfit it with some modern luxuries. For example: help add retrofit TPMS kits to older or non-TPMS-equipped vehicles.
- Programmable Module Installation (PMI) – Mainly for For-d models. Make adaptive procedures for new ECU modules after replacement to ensure their normal functionalities.
35+ commonly used repair & maintenance services, keep creasing
1.ABS Bleeding
When the ABS contains air, the ABS bleeding function must be performed to bleed the brake system to restore ABS brake sensitivity.
2.TPMS Reset
When due to the tire pressure is too low,tire leaks,tire pressure monitoring device is replaced or installed,tire is replaced and tire pressure sensor is damaged,The tire pressure resetting function must be performed to reset tire pressure and turn off the tire pressure MIL.
3.Oil Lamp Reset
Allows you to perform reset for a new calculation of Engine Oil life system once changed the oil.
4. Electronic Throttle Sensor Reset
To utilize the car decoder to initialize the throttle actuator so that the learning value of the ECU returns to the initial state.
5.Injector Coding
After the ECU or injector is replaced, injector code of each cylinder must be confirmed or re-coded so that the cylinder can better identify injectors to accurately control fuel injection.
6. SAS Reset
It helps clear the faulty steering angle sensor memories to reset the steering angle and plays an important role in the steering angle sensor calibration.
7.Brake-pad Reset
To deactivating and activate the brake control systems, assist with brake fluid control, open and close brake pads, and set brakes after disc or pad replacement.
8.Gear Learning
Perform gear learning for the car when the engine ECU, the crankshaft position sensor, or the crankshaft flywheel is replaced.
9.IMMO Service
To prevent the car being used by unauthorized keys, the anti-theft key matching function must be performed so that the immobilizer control system on the car identifies and authorizes remote control keys to normally use the car.
10.Battery Matching
Enables you to perform resetting operation on the monitoring unit of battery,in which the original low battery fault information will be cleared.
11.DPF Regeneration
It is used to clear PM (Particulate Matter) from the DPF filter through continuous combustion oxidation mode. Specially works for Diesel Particulate Filter system with DPF.
12.EGR Adaption
This function is used to learn the EGR (Exhaust Gas Recirculation ) valve after it is clean or replaced.
13.Suspension Matching
When replacing the body height sensor in the air suspension system, or control module or when the vehicle level is incorrect, this function can adjust the body height sensor for level calibration.
14.NOx Sensor Reset
If the NOx fault is re-initialized and the NOx catalytic converter is replaced, it is necessary to reset the catalytic converter learned value stored in the engine ECU.
15.Tyre Reset
This function is used to set the size parameters of the modified or replaced tire.
16.Windows Calibration
This feature is designed to perform door window matching to recover ECU initial memory.
17.Stop-start Reset
This function is used to open or close the automatic Start/Stop function via setting the hidden function in ECU (The precondition is the vehicle equipped with hidden function and hardware support)
18. AC Initialization
AC system relearn/initialization must be performed when the vehicle AC ECU or actuator is replaced or the ECU memory is lost.
19. AdBlue Reset
After the diesel exhaust treatment fluid (car urea) is replaced or filled up, the urea reset operation is required.
20. AFS Headlamp Reset
This function enables you to initialize the adaptive headlamp system.
21. A/F Reset
This function is applied to set or learn air/fuel rate parameters.
22. Gearbox Reset
This function enables you to complete the gearbox self-learning to improve gear shifting quality
23. Coolant Bleeding
Use this function to activate the electronic water pump before venting the cooling system.
24. Transport Reset
To lower vehicle power consumption, user may perform the following operations: limit vehicle speed, not wake up the network for door open and disable remote key, etc. In this case, deactivating the transport mode is needed to recover the vehicle being normal.
25. Seat Calibration
This function is applied to match the seats with memory function that are replaced and repaired.
26. High Voltage Battery Detection
This function is used for high voltage battery diagnosis and status information detection.
27. Sunroof Initialization
This function enables you to set the sunroof lock off, closed when it rains, sliding / tilting sunroof memory function, temperature threshold outside the car ,etc.
28. Engine Power Balance Monitoring
This function is used to monitor crankshaft acceleration in the power stroke of each cylinder, to determine the relative power provided by each cylinder.
29. Language Change
This function is used to change system language of vehicle center console.note:you need to have language pack to do language change
30. Gas Particulate Filter (GPF) Regeneration
This function is used to perform the GPF replacement or regeneration after the fuel consumption is increased and engine output power is reduced resulting from a long time service of the GPF.
31. Intelligent Cruise Control System Reset
This function is used to matching the intelligent cruise control module after it is replaced or repaired.
(Note: Available maintenance functions vary depending on the vehicle make, year, and model.)
Applications
- For Toyota: A/T Code Registration & Reset, Beam Axis Adjustment, Camera Axis Adjust, Check Mode, Height Offset, ID Information Display, Pilot Quantity Learning, Starter Exchange, Wireless Code Erasure …
- For Honda: Deflation Warning System, SWS Initialization, EOL Learn Gear, EOL Learn Synchronizing In Sequence, HV Battery Diagnosis, Yaw Rate/Lateral Acceleration Sensor …
- For For-d: Clear Crash Data Memory, Misfire Test, Relative Compression, (SCR) Emptying & Refill Activation & Parameter Reset & Visual Leak Check & Dosing Measurement Test & DEF Injector Cleaner …
- For Ben-z: Abort Road Test, Towing Sensor, Rain/light Sensor, Enabling of engine start after the crash event, High-voltage component l-ock, Reset offset value of signal “Longitudinal Acceleration” …
- For BM-W: Idle Speed, Injection Quantity Compensation, Write Service History, Simple Service Correction, Line Short Circuit Of FRM Reset, Folding Mirror Delay Time …
- For VW/Au-di: High-voltage Restart, Activate/Deactivate Seat Belt Warning Device, Seat Belt Tensioner Control Module Basic Setting …
How to Get 100+ More:
- Read vehicle by Auto detect or manual input or manual selection.
- Auto scan all accessible system on board.
- Relevant System: e.g. Powertrain/Body/Chassis, etc.
- Relevant Module: e.g. PCM/ECM/EPS/PDM/BCM/TPM/SCCM/RADIO, etc.
- Select the special function you need.
Share Report via Wi-Fi & print Report
Rather than taking the additional hassle, with this LAUNCH scanner, you would easily be able to share the diagnostics report to your clients or technicians via Wi-Fi ( email address ) . They would take a look at the full, clear, and accurate diagnostic report, and then understand what would need to be done. No more Googling unreliable fixes that would waste your energy.
Over 115 Car Brands ,10000+ Models
- American cars
for BUICK, for CADILLAC, for CHEVROLET, for CHRYSLER, for DODGE, for FIAT(BRAZIL), for FORD, for GM, for JEEP, for LINCOLI, for GM(BRAZIL)
- European car
, for ABARTH, for ALFA ROMEO, for AUDI, for BENTLEY, for BMW, for BUGATTI, for CITROEN, for DACIA, for IZH, for EURO FORD, for FERRARI, for FIAT, for GAZ, for OPEL(SOUTHAFRICA), for IVECO, for JAGUAR, for LAMBORGHINI, for LANCIA, for LANDROVE, for MASERATI, for MAYBACH, for MERCEDES, for MINI, for OPEL, for PEUGEOT, for PORSCHE, for RENAULT, for ROLLSROYCE, for ROVER, for SAAB, for SEAT, for SKODA, for SMART, for SPRINTER, for VAUXHALL, for VAZ, for VOLVO, for VW, for ASTONMARTIN, for VW_CV
- Asian cars:
for CURA, for DAEWOO, for DAIHATSU, for HOLDEN(AUSTRALIA), for HONDA, for HYUNDAI, for INFINITI, for ISUZU, for KIA, for LEXUS, for LUXGEN, for MAHINDRA(INDIAN), for MARUTI(INDIAN), for MAZDA, for MITSUBISHI, for NISSAN, for GTR(NISSAN), for PERODUA, for SAMSUNG, for SSANGYONG, for SUBARU, for SUZUKI, for TATA(INDIAN, for TLISUZU, for TOYOTA
Product Specifications:
Operating system: Android 10.0
Processor: 2.0GHz, quad core
Memory: 4GB
Storage: 64GB
Display screen: 7-inch, LCD screen
Resolution: 1024 * 600
Camera: 8 megapixel rear mounted
Wi Fi: 2.4GHz
Battery: 6300mAh
Launch CRP919X BT vs CRP919X vs CRP909X
Package List:
1* CRP 919X BT
1* DBScar VII VCI Connector
1* OBDII Diagnostic cable
1* 5V DC Charging Adaptors & Cable
1* Power adaptor
1* Quick start Guide
1* User's Manual
1* Password envelope
1* Type-A to Type-C USB cable
1* LAUNCH Suitcase
