Product Description

Launch X431 PRO 5 PRO5 diagnostic Tool with SmartLink C2.0 Can Fd and DoiP and Topology Mapping

• New Arrivals ！NEWEST X431 PRO5 with Smartlink 2.0 VCI !
• Super-remote service support is available (requires additional purchase of remote service). license comes with 3 times, if times run out, you need to buy extra.
• Dual diagnosis mode (local diagnosis and super remote diagnosis)
• Online Programming for BMW & Benz.
• Adds Topology Mapping function
• No IP limitation, 2 Years Free Update Online, 1 Year subscription is $350/year./ 2 years subscription $399
• Multilingual Support: English, German, French, Spanish, Portuguese, Italian, Russian, Polish, Romanian, Dutch, Arabic, Czech, Danish, Greek, Persian, Finnish, Hungarian, Swedish, Turkish, Serbian, Croatian, Chinese Simplified, Traditional Chinese, Japanese, Korean.
• ECU Coding & Programming via Smartlink 2.0 VCI ( Used as J2534).
• Advanced Intelligent Diagnostics – AutoVIN & AutoScan accelerates all-systems DTC scans that clock in at an average of < 3 minutes.
• Send Commands with Bi-directional Controls – Effectively test car components on demand.
• FCA AutoAuth Access – Bypass SGM in FCA vehicles seamlessly and within seconds; works on 2017 and later Chrysler, Dodge, Jeep, Alfa Romeo, Fiat, etc. *Need AutoAuth subscriptions.
• VAG Guided Function – Skip the routine procedure of entering the security access code & channel number for VW, Audi, Skoda, Seat vehicles.
• Non-16pin Connectors & Cables Kit: Enable to work on varied vehicles across the world.
• User-Oriented - One-touch software updates
• Great Combination: Android 10.0 O S, 4-core 2.0 GHz processor, 4GB RAM; 64GB ROM, 10.1'' HD 1280*800 touchscreen, 8MP rear; 5MP front camera, 7000 mAh battery, etc.
• Available to purchase Europe Professional Software License Pack( SGW Mercedes 1 Year, Renault & Dacia 20 Connections, FCA& Maserati 1 Year) in Mall
• Diagnostic Report Printing; One-click Updating; Data Recording; 4-in-1 Data Stream Display

Add Modules to Expand Features

X431 ADAS Moblie/ ADAS PRO: Calibrate a wide range of camera-based & radar-based driver assistance systems
PROG-3 Key Matching: IMMO For VAG Group Above 3.5, Vehicles that require cloning are not compatible with this accessory
WIFI Printer (Print out diagnostic data/ reports.)
BST360 battery test.(For Battery Cranking system Test, Battery Charging system Test, Battery Health Test)
Launch VSP-600 Video Scope: Check unseen parts and give you a direct image of the engine, gears, compressors, headers and valves, and body components.
TSGUN (Not only can you use it to activate the sensor's ID, tire pressure, sensor frequency, tire temperature, and battery status.)
Heavy Duty Module: Working on both heavy-duty (Class 4 through 8) and medium-duty trucks (Such as heavy trucks, city buses, bulldozers, excavators, etc.)
O2-2 Scopebox: detects high level faults on various electrical components, such as sensors, acturators and circuits.
S2-2 Sensorbox: diagnosing/testing/simulating most vehicle sensor faults

Newly Added Functions:

Adds Launch X431 key programmer for remote generation (Only new PRO5 with SmartLink)
Adds EV diagnostic kit for new Energy Battery Vehicles
Launch IMMO Function Update Service (Activate IMMO Plus/IMMO Elite Function)
Launch Motorcycle Diagnostic Connector Kit 2.0 with Software License
Launch Motorcycle Diagnostic Connector Kit V3 +License (Newly add VSP‑3PIN, VSP‑6PIN, BRP, and KTM motorcycle diagnostic connectors, a dual‑clamp power cable, and a multi‑purpose adapter)

Notice:
*The new version of PRO5 replaces the VCI from Smartbox 3.0 with SmartLink C2.0 ( new vci same as PAD VII). Super-remote service support is available (requires additional purchase of remote service).
*Online programming is not supported in: USA, Canada, Mexico, Portugal, and Spain.

Why buy Launch X-431 Pro5 from us?

1. Launch X431 is a global leading brand, popular among customers, and worth trusting.
2. We are an Authorized Launch Dealer, Guarantee it is a 100% Original Launch machine.
3. All products have been passed the strict quality test before shipment, make sure high quality.
4. GLOBAL VERSION, NO IP LIMITATION.

New Pro5 Smartlink vs Old Pro5

Tablet configuration and functions are the same. New Pro5 comes with Smartlink C 2.0 passthru VCI which supports dual diagnosis mode: local diagnosis and super remote diagnosis. old Smartbox 3.0 only local diagnosis.



Newly Add Online Programming for BMW & Benz(need configuration, check how to setting X431 PRO 5 online programming)

LAUNCH X431 PRO5 scanner programming tool allows you directly download OEM programming software and program data into vehicle ECUs (for BMW & Mercedes-Benz series). It takes better care of all the situations that need ECU programming and achieves dual programming (Automatic+Manual) modes to save failed programming. Whenever you need it, it will be there.

• Replace New Blank Modules: Some parts or modules physically need to be replaced. LAUNCH X431 PRO5 can help you to program adaptive data to make the new modules communicate with other modules.
• Repair ECU with Data Loss: Suit for insufficient car battery voltage resulting in module data loss.
• Upgrade ECU Software Version: Require upgrade to fix bugs in module software and get more new functions.
• Reprogramming Operation (Exclusive!): Restore original software data when module programming failed.
• Note: You need to message our post-sale for get the operation access of “Online Programming Function” for BMW & Benz. and the online programming Can't perform in Portugual, Canada and Spain

Launch X-431 PR05 Descriuption:

X-431 PR05, the innovative revolution of intelligent diagnosis. It opens the era of dual diagnostic modes . X-431 PRO5 not only inherits the powerful diagnostic strength of the PRO series but also supports SmartLink remote diagnosis and requests support from SmartLink B of the third-party diagnostic devices that support Launch's diagnostic tools, J2534 and specialized detection equipment, with features not limited to the diagnostic functions of the device under control.

LAUNCH X431 PRO5 Functions:

1. J2534 ECU Pro & ECU Coding Up Your Business To Higher Level

For repair shops that tend to expand your businesses to high-end vehicle models like Ben-z, B-MW, Porsche, this LAUNCH scanner X431 PRO5 will make your plans come true. LAUNCH auto scanner X431 PRO5 work with SmartLink C (J2534 compliant) empowers you to conduct J2534 ECU Pro, just by downloading the OEM software in Automakers’ Service Webs to show the OE-level pro.

What can this J2534 Pro Function do for you?

1) Operate OEM pro without using the OEM tools
2) Replace ECUs: pro blank ECUs
3) Write-in Data: refresh used ECUs
4) Repair missing ECU information
5) Upgrade ECU software version

2. Advanced ECU Coding

Serving as an upper-level function that not only creates the vehicle’s potential but also increases your profits. These automatic functions save us work & time and allow us to concentrate on our driving experi-ence mostly.

1) Component Matching: Match the ECU modules after changing and replacement.

2) Flash Hidden Functions: Activate advanced functions or Disable Vehicle Functions: like Deactivating the Start/Stop Function; Beeping When Unlocking and Locking; Seatbelt Warning Sounds; Mirrors Automatically Folding and Unfolding; and more.

3) Online ECU Cod-ing: Allow you to get more online ECU data from the OEM server, making cod-ing easier and more accurate. Designed for VW, A-u-d-i, B-MW, Porsche, etc.

NOTE: ECM writing via J2534 is model-specific & needs OEM software download. Please verify compatibility before purchase.

3. Bi-Directional Control for Fast Troubleshooting

The Bluetooth Diesel Diagnostic Tool X431 PRO5 features Bi-directional Control, also known as Active Test, Actuator Test, and Inspection Tests. It can send the commands to ECUs, read the ECU data to determine the completeness of the system or parts, and monitor the operation of the actuators, letting you quickly know if a specific system, component, or subsystem is functioning properly or not.

With this bidirectional scan tool, you don't need to struggle to disassemble individual on-board parts & ECUs to find a small problem. It also can be universally applied to all the vehicle systems like ABS, SRS, Engine, TPMS, BCM, Headlamps, Windscreen Wipers, Windows, Doors, Sunroof, Mirrors, for pinpointing problems within 5 minutes.

Here we have some examples for the A-ctive test:

Switch the SRS light on and off;
Cycle the a/c clutch on and off;
Switch the cylinder on and off;
Conduct the injector buzz test;
Turn on/off the radiator fan;
Operate the acceleration device test;
Note: Not universal for all vehicles. Available tests vary depending on the make, year, and model.



4. Guided Functions

LAUNCH diagnostic tool provides OE-level operating instruction for reference and simplifies the complex diagnostics, which will save the diagnostic time and improve the technician’s efficiency. Compatible with VW, A-u-d-i, Seat, Skoda, Porsche, etc.

5. Advanced ALL Systems Diagnoses
This LAUNCH diagnostic scanner can establish a data link to all systems and subsystems of the vehicle being serviced to:
1) Retrieve ECU information including unit type, version numbers, and other specifications, etc.
2) Read & erase DTCs to locate problem areas and clear the codes.
3) View Live Data of each parameter item.
4) This comprehensive scanning process is able to locate the faulty systems and retrieve the DTCs related easily. So you can work on all parts of the vehicle systems to enhance performance, save energy, reduce emissions, and everything else.



6. 50+ Hot Reset & Relearn Maintenance Services
You can easily choose multiple commonly-used service functions, follow their clear and precise instructions to complete complex projects much faster, including but not limited to the following:

• Oil Maintenance Light Reset: reset the oil service lamp; re-calculate the optimal oil life change interval.
• Steering Angle Reset: reset the steering angle to zero to keep the car running straight.
• Injector Coding: write the new injector code into the system to correct cylinder injection quantity.
• Electronic Parking Brake Reset: help replace and reset the brake pad.
• ABS Bleeding: help exhaust the air in ABS system in an easy way.
• Throttle Matching: initialize the throttle actuators to the default state.
• Battery Matching: register the battery after replacement.
• DPF Regeneration: help remove the particulate matter to keep the trap stable.
• Anti-theft Matching (IMMO Service): disable lost keys to prevent the car from being stolen, and add new keys. *Limited in default; can be fully upgraded with X-PROG & X-PROG3.
• Tire Pressure Reset: reset the tire pressure.
• Suspension Level Calibration: adjust the vehicle body height sensor for level calibration.
• Headlight Matching: initialize the adaptive headlamp system.
• Gearbox Matching: help complete the gearbox self-learning to improve gear shifting quality.
• Sunroof Initialization: initialize the sunroof when to be locked off, or closed.
• Tooth Learning: help to finish tooth learning after changing crankshaft in the car engine.
• NOTE: Explore more service functions by accessing menus of Vehicle Brand -> System Diagnostics -> Special Function.

And many more with expanding. Function menus vary by manufacturer, year, and model. Reach us for compatibility check.
NOTE: *Explore more service functions by accessing menus of “Vehicle Brand -> System Diagnostics -> Special Function”.




7. TPMS Programming
Activate all sensors, TPMS relearn, Program

8. AUTO VIN: Maximize Your Intelligence
This intelligent scanner will automatically identify the make, model, and manufacture year in one touch; help you match the right software so the diagnosis will be carried out fast and efficiently. You will also enjoy how smart it would be to record the test results as Inspection Report, being done by itself, letting you maintain vehicle health logs and share the information easily.

9. Remote Diagnosis
Users can carry out the remote diagnosis to ask for the remote control from other LAUNCH diagnostic tools (including but not limited to V+ 4.0), which are equipped with the remote diagnosis module as well, or from a PC client technician. This has realized the reality that a mechanic can diagnose an abnormal vehicle, which is even thousands of miles away.

10. Health Report Generate and Share
With LAUNCH X431 Pro 5, you can generate a full system Diagnostic Report by ONE-CLICK. The reports can be emailed to the office or directly to your customer. You can also print out the vehicle health report card.

11. Print Diagnostic Result
You can share car diagnostic data via email, then print it via PC or optional wifi, and you can order Launch x431 mini wifi printer, then one-key printing.

12. Boost Your Efficiency
See what your car is doing in real-time; get car performance, sensor data, and more at one glance!
This diagnostic scanner presents the live data stream in 3 modes:
a. Numbers and lists (default);
b. Wave patterns (max. 12 channels on one screen);
c. Merged graph (max. 4 data can be merged) for you to quickly identify if the data are in normal conditions, ranges, or not.

13. ADAS Calibration

ADAS is a helping hand when sleepy drivers accidentally swerve out of their lane and into another car. And ADAS calibration of X431 Pro5 scanner helps you to effectively and accurately calibrate a wide range of camera-based & radar-based driver assistance systems.
It is needed during the following scenarios:
1) Windshield replacement;
2) Collision;
3) Replacement change in tires or ride height;
4) ADAS lights are on or flashing; That will make your driving exper-ience safer than ever before.

Comparison among Launch:

New Launch X431 Pro5 SmartLink C2.0 VS Old Launch X431 Pro5 Smartbox 3.0

New X431 Pro5 is with Smartlink C 2.0 VCI  supports dual diagnosis mode: local diagnosis and super remote diagnosis. but Smartbox supports only local diagnosis.

Item	Model	X431 PRO5 Smartbox 3.0	X431 PRO5 SmartLink 2.0
Hardware Configurations	CPU	8-Core Processor, 1.8 GHz	4-Core Processor, 1.8 GHz
	ROM	64G	64G
	RAM	4G	4G
	battery capacity	7000 mAh / 3.8V	7000 mAh / 3.8V
	Android version	Andorid 9.0	Andorid 10.0
	Screen Size	10.1-Inch	10.1-Inch
	Screen resolution	1920*1080	1280*800
	Wi-FI	2.4GHz /5GHz	2.4GHz /5GHz
	Camera	Rear 8.0MP, Front 5.0MP	Rear 8.0MP, Front 5.0MP
	Remote Communication	Local Diagnosis: WiFi/BT/USB	Local Diagnosis: WiFi/BT/USB SmartLink Remote Diagnosis: WiFi/Ethernet
	VCI	Smartbox 3.0	SmartLink 2.0
Main Features	Basix Functions (Read & Clear the codes and data stream)	√	√
	Service Function	31	33+
	Full System Diagnosis	√	√
	Active test	√	√
	Auto VIN	√	√
	SCAN VIN/License	√	√
	Remote Desk	×	√
	Diagnostic Topology Display	√	√
Online Programming	Benz	√	√
	BMW	√	√
	VW, Audi, Skoda, SEAT	×	×
	Porsche	×	×
	Land Rover	×	×
	Jaguar	×	×
	Renault	×	×
	Nissan	×	×
	Subaru	×	×
	Infiniti	×	×
	Hyundai	×	×
	Kia	×	×
Online Parameterization	VW	×	×
	Audi	×	×
Online Coding	BENZ (SCN)	√	√
	BMW	√	√
	VW, Audi, Skoda, SEAT	√	√
	Porsche	√	√
	Renault	×	×
Online FFS Activation	VW, Audi	√	√
Online Calibration & Matching	VW, Audi	√	√
Guided Function	VW, Audi, Skoda	√	√
Offline Programming	Ford	√	√
	Mazda	√	√
	Vauxhall	√	√
	Opel	√	√
Flash Hidden Function	Benz	√	√
	BMW	√	√
	VW, Audi, Skoda, SEAT	√	√
	Porsche	√	√
	Jeep	√	√
	Dodge	√	√
	Chrysler	√	√
	Toyota	√	√
	Honda	√	√
Repair Data	Benz	×	×
	BMW	×	×
	VW, Audi	×	×
	Porsche (11-)	×	×
Add-on Tools	Diesel Vehicle Diagnosis(HD)	√	√
	ADAS License	√	√
	TPMS(TSGUN)	√	√
	X-PROG 3	√	√
	Battery Tester	√	√
	Oscilloscope	×	×
	Endoscope	√	√
Protocol Supported	Diagnostic Protocols: D-PDU/J2534/RP1210	√	√
	Bus Protocols: DoIP/CAN FD	√	√
Subscription Fee	Tesla License	√ (Optional)	√ (Optional)
	FCA Secure Gateway	√	√
	Upgarde	2 Years Free Update	2 Years Free Update
Languages	Software Languages	English, Italian, German, Japanese, Russian, French, Spanish, Portuguese, Polish, Turkish, Dutch,  Greek, Hungarian, Arabic, Danish, Korean, Persian, Romanian, Serbian, Finnish, Swedish, Czech	English, Italian, German, Japanese, Russian, French, Spanish, Portuguese, Polish, Turkish, Dutch,  Greek, Hungarian, Arabic, Danish, Korean, Persian, Romanian, Serbian, Finnish, Swedish, Czech
	User Manual Language	English	English

Product Specifications:

Tablet Parameters( X-431 PRO5)

CPU: 2.0GHz 4-core
OS: Android 10.0
RAM: 4GB
ROM: 64GB
Display: 10.1 inch
Resolution: 1280*800
Camera: 5MP(Front), 8MP(Rear)
Wi-Fi: 2.4GHz/5GHz （Dual frequency）
Working Temperature: 0~50℃
Size: 274 *190.5 *39.5(mm)

VCI Parameters(SmartLink C)

Processor: Cortex-A7+Cortex-M7
OS: Linux
RAM: 256M
ROM: 8GB
Display: 3.5 inch touch screen
Wi-Fi: 2.4GHz/5GHz dual-band
Diagnostic Communication: WiFi&BT&USB
Test Voltage: DC 9~36V
Working Temperature: 0~50℃
Size: 204*110*45 (mm)

X431 Pro 5 Package Includes:

1pc x main unit
1pc x SmartLink C V2.0
1pc x US plug
1pc x EU plug
1pc x UK plug
1pc x OBD adapter
1pc x Type-C cable
1pc x USB-B cable
1pc x Ethernet cable
1pc x quick start guide
1pc x PIN envelope
1pc x user manual
